DBA 5000 series T3 Slotted Rotor Only Left Hand Brake Disc 380mm x 36mm 72 Curved Vanes DBA52972.1LS

Make	Model	Sub Model	Year

- Weight
  25.2 KG
- SKU
  DBA52972.1LS
Brand
dba
Tech Bulletins
Bedding in Brakes https://ozparts.eu/pdf/Technical-Bulletin-Bedding-In-Brakes.pdf | How to clean a Disc Rotor before fitting https://ozparts.eu/pdf/Technical-Bulletin-How-to-clean-a-Disc-Rotor-before-fitting.pdf | Motorsport - Important Info https://ozparts.eu/pdf/Technical-Bulletin-Motorsport-Information.pdf
Thickness mm
36
Diameter mm
380
Disc Vent
72 Curved Vanes
Stage
Stage 5
Air Gap mm
17
Annulus mm Maximum useable pad width
72
Diameter & Number of Bolt Holes mm
9.05 (x12)
Flange Inside Diameter mm
195
Flange Thickness mm
7
Hole Type
Round Hole
Pitch Circle Diameter P.C.D
214,2
Offset mm
No
Inside Diameter mm
236
Replacement Nuts
Not Included
