DBA 5000 series T3 Slotted Rotor Only Left Hand Brake Disc 328mm x 28mm 60 Curved Vanes DBA52974.1LS

Make	Model	Sub Model	Year

- Weight
  14.8 KG
- SKU
  DBA52974.1LS
Brand
dba
Tech Bulletins
Bedding in Brakes https://ozparts.eu/pdf/Technical-Bulletin-Bedding-In-Brakes.pdf | How to clean a Disc Rotor before fitting https://ozparts.eu/pdf/Technical-Bulletin-How-to-clean-a-Disc-Rotor-before-fitting.pdf | Motorsport - Important Info https://ozparts.eu/pdf/Technical-Bulletin-Motorsport-Information.pdf
Thickness mm
28
Diameter mm
328
Disc Vent
60 Curved Vanes
Stage
Stage 5
Air Gap mm
13,5
Annulus mm Maximum useable pad width
54
Diameter & Number of Bolt Holes mm
8.15 (x10)
Flange Inside Diameter mm
184
Flange Thickness mm
6
Hole Type
Elongated Hole
Pitch Circle Diameter P.C.D
206
Offset mm
Yes
Inside Diameter mm
220
Replacement Nuts
Not Included
