DBA 5000 series T3 Slotted Rotor Only Left Hand Brake Disc 308mm x 26mm 60 Curved Vanes DBA52231.1LS

Make	Model	Sub Model	Year

- Weight
  5.5 KG
- SKU
  DBA52231.1LS
Brand
dba
Tech Bulletins
Bedding in Brakes — https://ozparts.eu/pdf/Technical-Bulletin-Bedding-In-Brakes.pdf | How to clean a Disc Rotor before fitting — https://ozparts.eu/pdf/Technical-Bulletin-How-to-clean-a-Disc-Rotor-before-fitting.pdf | Motorsport - Important Info — https://ozparts.eu/pdf/Technical-Bulletin-Motorsport-Information.pdf
Thickness mm
26
Diameter mm
308
Disc Vent
60 Curved Vanes
Stage
Stage 5
Air Gap mm
14
Annulus mm Maximum useable pad width
47,5
Diameter & Number of Bolt Holes mm
6.4 (x12)
Flange Inside Diameter mm
174
Flange Thickness mm
6,6
Hole Type
Round Hole
Pitch Circle Diameter P.C.D
190,5
Offset mm
No
Inside Diameter mm
213
Replacement Nuts
Included
